| Part No. | Feild Angles | CCT (Typ.) | Lux@ 1m (Typ.) | Lm (Typ.) | |||||
| TD36C-1541xx | 45° (B.A.25°) | 6000K | 6900 | 1380 | |||||
| TD36C-1542xx | 45° (B.A.25°) | 4000K | 6500 | 1270 | |||||
| TD36C-1543xx | 45° (B.A.25°) | 3000K | 6000 | 1160 | |||||
| TD36C-1571xx | 70° (B.A.38°) | 6000K | 2600 | 1380 | |||||
| TD36C-1572xx | 70° (B.A.38°) | 4000K | 2500 | 1270 | |||||
| TD36C-1573xx | 70° (B.A.38°) | 3000K | 2200 | 1160 | |||||
| CRI | Voltage | Aperture | Weight | ||||||
| 75 (cool white) | DC 21V, 700mA | 115mm - Tiltable | 350g - Tiltable | ||||||
| 80 (Neutral white) | 110mm - Fixed | 310g - Fixed | |||||||
| 80 (warm white) | |||||||||
| Type | Finished Colors | ||||||||
| Tiltable, Fixed | White, Silver, Alu. Brushed | ||||||||
| Part No. | Feild Angles | CCT (Typ.) | Lux@ 1m (Typ.) | Lm (Typ.) | |||||
| TD36C-1541xx | 45° (B.A.25°) | 6000K | 6900 | 1380 | |||||
| TD36C-1542xx | 45° (B.A.25°) | 4000K | 6500 | 1270 | |||||
| TD36C-1543xx | 45° (B.A.25°) | 3000K | 6000 | 1160 | |||||
| TD36C-1571xx | 70° (B.A.38°) | 6000K | 2600 | 1380 | |||||
| TD36C-1572xx | 70° (B.A.38°) | 4000K | 2500 | 1270 | |||||
| TD36C-1573xx | 70° (B.A.38°) | 3000K | 2200 | 1160 | |||||
| CRI | Voltage | Aperture | Weight | ||||||
| 75 (cool white) | DC 21V, 700mA | 115mm - Tiltable | 350g - Tiltable | ||||||
| 80 (Neutral white) | 110mm - Fixed | 310g - Fixed | |||||||
| 80 (warm white) | |||||||||
| Type | Finished Colors | ||||||||
| Tiltable, Fixed | White, Silver, Alu. Brushed | ||||||||
