| Part No. | Feild Angles | CCT (Typ.) | Lux@ 1m (Typ.) | Lm (Typ.) | |||||
| TD16C-0541xx | 45° (B.A.25°) | 6000K | 2400 | 420 | |||||
| TD16C-0542xx | 45° (B.A.25°) | 4000K | 2200 | 390 | |||||
| TD16C-0543xx | 45° (B.A.25°) | 3000K | 2000 | 350 | |||||
| TD16C-0571xx | 70° (B.A.38°) | 6000K | 850 | 420 | |||||
| TD16C-0572xx | 70° (B.A.38°) | 4000K | 800 | 390 | |||||
| TD16C-0573xx | 70° (B.A.38°) | 3000K | 750 | 350 | |||||
| CRI | Voltage | Aperture | Weight | ||||||
| 75 (cool white) | DC 16V, 350mA | 74mm | 120g | ||||||
| 80 (Neutral white) | |||||||||
| 80 (warm white) | |||||||||
| Type | Finished Colors | ||||||||
| Tiltable | White, Silver, Alu. Brushed | ||||||||
| Part No. | Feild Angles | CCT (Typ.) | Lux@ 1m (Typ.) | Lm (Typ.) | |||||
| TD16C-0541xx | 45° (B.A.25°) | 6000K | 2400 | 420 | |||||
| TD16C-0542xx | 45° (B.A.25°) | 4000K | 2200 | 390 | |||||
| TD16C-0543xx | 45° (B.A.25°) | 3000K | 2000 | 350 | |||||
| TD16C-0571xx | 70° (B.A.38°) | 6000K | 850 | 420 | |||||
| TD16C-0572xx | 70° (B.A.38°) | 4000K | 800 | 390 | |||||
| TD16C-0573xx | 70° (B.A.38°) | 3000K | 750 | 350 | |||||
| CRI | Voltage | Aperture | Weight | ||||||
| 75 (cool white) | DC 16V, 350mA | 74mm | 120g | ||||||
| 80 (Neutral white) | |||||||||
| 80 (warm white) | |||||||||
| Type | Finished Colors | ||||||||
| Tiltable | White, Silver, Alu. Brushed | ||||||||
